Busbar 150A 6P/Terminals & Cover
📝 Victron 150A 6-Post Busbar with Cover
The Victron 150A 6-Post Busbar with a protective insulated cover delivers reliable high-current distribution in a compact, professional-grade design. Ideal for marine, RV, solar, and off-grid installations, this busbar centralizes DC connections, improving safety, efficiency, and organization within your electrical system.
⭐ Essential Benefits
• 150A continuous current rating – ensures consistent, high-current performance for demanding DC systems.
• 6-post configuration – distributes power evenly across multiple circuits and components.
• Protective cover included – prevents accidental shorting and shields terminals from dust and debris.
• Molded stainless steel studs – allow high-torque fastening and durable electrical contact.
• Corrosion-resistant construction – built for long-term use in marine and off-grid environments.
• Raised bus design – simplifies wire management and provides easy multi-cable access.
• Pre-drilled mounting holes – enable quick, secure installation.
• Clean professional layout – reduces cable clutter for an organised, serviceable setup.
⚙️ Functionality
The Victron 150A 6P Busbar acts as a central distribution hub for high-current DC circuits. It provides a safe, efficient way to connect multiple loads or battery systems to a shared power source while maintaining low resistance and excellent electrical conductivity.
🔌 Compatibility
• Compatible with 12v, 24v, and 48v DC systems
• Ideal for Victron Energy systems and other DC setups
• Suitable for marine, caravan, RV, off-grid, and solar applications
• Works with batteries, inverters, charge controllers, and fuse panels
🧰 Installation Difficulty
🟢 2/5 (Easy) – simple installation using pre-drilled holes and standard tools.
🔍 Features
• Rated for 150A continuous current
• 6 × M6 stainless steel posts for multi-circuit distribution
• Nickel-plated copper bar ensures efficient current flow
• Insulated protective cover included
• Raised bus design for easy wiring and inspection
• Pre-drilled mounting holes for secure setup
• Corrosion-resistant materials for harsh environments
• Compact footprint for tight compartments
• Suitable for both positive and negative bus connections
• Built to Victron Energy’s premium quality standards
📊 Specifications
| Specification | Detail |
|---|---|
| Continuous Current | 150A |
| Voltage Rating | Up to 70V DC |
| Terminals | 6 × M6 stainless steel posts |
| Material | Nickel-plated copper bar |
| Cover | Insulated protective cover (included) |
| Mounting Holes | Pre-drilled |
| Dimensions | 220 × 35 × 35mm (approx.) |
| Operating Temperature | -40°C to +85°C |
| Application | DC power distribution |
📦 What’s Included
• 1 × Victron 150A 6-Post Busbar
• 6 × M6 nuts and washers
• 1 × Protective insulated cover
