Victron Orion XS 1400 (12V & 24V) DC-DC Smart Battery Charger
📝 Victron Orion XS 1400 (12V & 24V) DC-DC Smart Battery Charger
The Victron Orion XS 1400 DC-DC Smart Battery Charger is a high-performance, next-generation charger designed for 12v and 24v systems. It delivers precise current control, intelligent adaptive charging, and outstanding energy efficiency up to 98%, all in a compact, fanless aluminium housing. Ideal for RVs, boats, caravans, and off-grid systems, the Orion XS 1400 ensures your batteries charge faster, last longer, and perform at their best.
⭐ Essential Benefits
• Ultra-high 98% efficiency – advanced aluminium circuit board cooling eliminates fans, minimising heat and power loss.
• Adjustable current control – fine-tune input and output from 1A to 50A (0.1A increments) via the VictronConnect app.
• Intelligent adaptive charging – 4-stage algorithm optimises charge for lead-acid and lithium batteries.
• Dual-voltage compatibility – suitable for both 12v and 24v systems, ideal for multi-voltage setups.
• Advanced electronic protection – safeguards against overloads, short circuits, overheating, and undervoltage.
• Smart connectivity – configure and monitor in real time via Bluetooth or VE.Direct port.
• Power supply mode – operate as a stable DC power source when battery charging is not required.
• IP65 rating – dust and water-resistant construction ensures reliable performance in harsh environments.
⚙️ Functionality
The Orion XS 1400 provides intelligent DC-DC charging and voltage conversion, ensuring safe and efficient power management for service batteries in modern vehicles and vessels. It maintains full output performance up to 40°C, supports recovery from deep discharge, and prevents input battery drain with its low-voltage lockout feature. With the VictronConnect app, users gain full control over system performance, current limits, and charge profiles directly from a smartphone or tablet.
🔌 Compatibility
• Works with 12v or 24v DC electrical systems
• Compatible with lead-acid and LiFePO₄ batteries
• Supports Euro 5 and Euro 6 smart alternators
• Ideal for boats, campervans, caravans, 4WDs, and off-grid systems
• Integrates with VictronConnect and VE.Direct for control and monitoring
🧰 Installation Difficulty
🟡 3/5 (Moderate) – compact, easy to mount design with clear terminal layout and protective cover for safe installation.
🔍 Features
• 1–50A adjustable input/output via VictronConnect
• 4-stage adaptive charge algorithm for optimal battery health
• Bluetooth Smart connectivity for wireless configuration
• VE.Direct communication port for system integration
• Remote on/off switching for flexible installation
• 98% efficiency with fanless cooling
• Short circuit, overload, and thermal protection
• IP65-rated aluminium casing – waterproof and dust-resistant
• Operates up to 40°C without performance loss
• Protective terminal cover for safety and cleanliness
📊 Specifications
| Specification | Detail |
|---|---|
| Input Voltage | 12v or 24v DC |
| Output Voltage | 12v or 24v DC |
| Output Current | 1–50A adjustable |
| Efficiency | Up to 98% |
| Cooling | Aluminium PCB (fanless) |
| Protection | IP65, short circuit, overload, over-temperature |
| Control | Bluetooth, VE.Direct, remote on/off |
| Charge Algorithm | Adaptive 4-stage (Bulk, Absorption, Float, Storage) |
| Operation Temp. | Full power up to 40°C |
| Application Type | DC-DC Smart Charger |
📦 What’s Included
• 1 × Victron Orion XS 1400 (12V & 24V) DC-DC Smart Battery Charger
• 1 × Protective terminal cover
• 1 × Installation guide
Data sheet here
Manual here
